| Product Code | G55 |
| Product Name | Woven Strapping - G55 - 16mm, 600 daN, 600m coil |
| Product Size | 16 mm (5/8") |
| Weight | 6.4800 KG |
| MOQ | 108 |
| Custom Tariff No. | 560750 |
| GTIN/EAN13 | 4251858210936 |
| Price |
Polyester Woven Strapping
Woven strapping belts are made of high tensile polyester yarns. Due to its material characteristics it has low elongation (below 10%), is highly tear proof and absorbs very little moisture. Furthermore the strapping can be retensioned in case of volume loss in the packaged goods and has a high breaking load, linear and within the system. Woven strapping belts will not splice, are flexible and universally applicable.
Specifications
| 1. Technical data | |
| Material | High tensile polyester yarns, woven |
| Material processing | Glue coated, pre tensioned and heat dried for higher strength |
| 2. Required standard | |
| Minimum linear breaking strength | 600 daN |
| Minimum system breaking strength | 880 daN |
| 3. Tested data | |
| Linear breaking strength | Test 1-5 (623, 618, 632, 628, 629 ) Avg 626 daN tested Oct 2017 |
| System breaking strength | see tested combination(s) below |
| System breaking strength+WB19P3.5 | Test 1-5 (839, 896, 835, 880, 908 ) Avg 872 daN tested Oct 2017 |
| System breaking strength+WB19N3.8 | Test 1-5 (896, 866, 849, 880, 908 ) Avg 880 daN tested Oct 2017 |
| 4. Shipping | |
| Custom Statistic code Tarif Number | 5806321000 |
| Place of Origin | China |
| Standard Container | |
| Items per Carton | 3 |
| Cartons per Palette | 36 |
| Net weight Carton | 19.83 KG |
| Gross weight Carton | 21.24 KG |
| Dimension Carton | 35 x 35 x 50 cm ( 0.06125m³ ) |
| Items on Palette | 108 |
| Palette size | 105*105*14.5 |
| Total weight per Palette | 757.44 KG |
| File Name | Description | File Size | Mime Type | |
|---|---|---|---|---|
| Woven Strap TUV report 2013.pdf | Woven Strap TUV report | 1423135 | application/pdf | |
| RoHSGW60PES.pdf | RoHs Report | 255694 | application/pdf | |
| SGSwovenBelts.pdf | SGS Report | 187370 | application/pdf | |
| REACH138_WOVEN STRAP.pdf | Reach Certificate | 293427 | application/pdf | |
| SVHC-5S Report Woven Strap.pdf | SVHC-5S Report | 1000154 | application/pdf | |
| 2017-SVHC-5 NEW-woven strap.pdf | 2017-SVHC-5 NEW-Report | 605518 | application/pdf | |
| Test_report_for_G55.pdf | G55 test report Oct 2017 | 231403 | application/pdf |
