| Product Code | 8022003 |
| Product Name | PP90 SV - 60x120cm, Woven PP Dunnage Air Bag |
| Product Size | 60x120 cm (24x48") |
| Weight | 0.3100 KG |
| MOQ | 1050 |
| Custom Tariff No. | 3923299000 |
| GTIN/EAN13 | 4251858230118 |
| Price |
Size: 60 x 120 cm ( 24" x 48" )
PP 90 Woven Dunnage Air Bag
Mainly used in intermodal containers, in transportation by rail or by road. The load parameters are fully absorbed i.e the dunnage bag must absorb the forces encountered during transit. In addition a polypropylene plastic offers 100% protection from water splashes, condensation or other miscellaneous moisure influences.
Material
Outliner: Woven polypropylene yarn medium
In liner: co-extruded PE mixes
Max. filling pressure: 20 kPa / 0.2 bar / 2.9 P.S.I)
ISO 9001: 2008 certified
SGS test report passed
TÜV certificate
Many sizes available
| Air Bag | |
| Material Inliner | Co extruded PE mix |
| Material Outliner | PP woven fabric |
| maximal filling pressure | 20 kPa / 0,2 bar / 2,9 P.S.I. |
| nominal burst pressure | 60 kPa / 0,6 bar / 8,7 P.S.I. |
| Valve | Standard OEMSERV ball head valve |
| Origin | |
| Custom Statistic code Tarif Number | 3923290000 |
| Place of origin | China |
| Standard Container | |
| Items per Carton | 350 |
| Cartons per Palette | 3 |
| Net weight Carton | 145.53 KG |
| Gross weight Carton | 158.03 KG |
| Dimension Carton | 100 x 124 x 59 cm ( 0.7316m³ ) |
| Items on Palette | 1050 |
| Palette size | 124*100*14.5 |
| Total weight per Palette | 418.44 KG |
| High Cube Container (HQ) | |
| Items per Carton | 450 |
| Cartons per Palette | 3 |
| Net weight Carton | 145.53 KG |
| Gross weight Carton | 158.03 KG |
| Dimension Carton | 100 x 124 x 69 cm ( 0.8556m³ ) |
| Items on Palette | 1350 |
| Palette size | 124*100*14.5 |
| Total weight per Palette | 513.77 KG |
| File Name | Description | File Size | Mime Type | |
|---|---|---|---|---|
| Dunnage Air Bags.m4v | Video of Dunnage Air Bags | 38296578 | video/mp4 | Download |
| PrSpSh_PP90airbagS.pdf | Product Specification Sheet | 878446 | application/pdf | |
| RoHsWovenBags.pdf | RoHs Report | 435199 | application/pdf | |
| SGSwovenBags.pdf | SGS Report | 162636 | application/pdf | |
| REACH138_PP AIR BAG.pdf | Reach Certificate | 254447 | application/pdf | |
| MSDS-PP Dunnage Bags.pdf | Material safety data sheet | 650446 | application/pdf |
