| Product Code | G200 |
| Product Name | Woven Lashing - G200 - 40mm, 5000/8500 daN, 200m in carton box |
| Product Size | 40 mm (7/4") |
| Weight | 18.6000 KG |
| MOQ | 45 |
| Custom Tariff No. | 5607500090 |
| GTIN/EAN13 | 4251858213043 |
| Price |
Polyester Woven Lashing
Woven lashing belts are made of high tensile polyester yarns. Due to its material characteristics it has low elongation (below 10%), is highly tear proof and absorbs very little moisture. Furthermore the lashing can be retensioned in case of volume loss in the packaged goods and has a high breaking load, linear and within the system. Woven lashing belts will not splice, are flexible and universally applicable.
Specifications
| 1. Technical data | |
| Material | High tensile polyester yarns, woven |
| Processing | Glue coated, pre tensioned and heat dried for higher strength |
| 2. Required standard | |
| Minimum linear strength | 5000 daN |
| Minimum system strength | 8000 daN |
| 3. Tested data | |
| Linear breaking strength | 5000 daN |
| System breaking strength | see tested combination(s) below |
| Linear breaking strength+GWS40RD | Test 1-5 ( 8286, 8384, 8300, 8563, 8392 ) Avg 8385 daN tested Jun 2017 |
| 4. Shipping | |
| Custom Statistic code Tarif Number | 5607500090 |
| Place of Origin | China |
| Standard Container | |
| Items per Carton | 1 |
| Cartons per Palette | 45 |
| Net weight Carton | 19.12 KG |
| Gross weight Carton | 20.52 KG |
| Dimension Carton | 40 x 40 x 40 cm ( 0.064m³ ) |
| Items on Palette | 45 |
| Palette size | 1200 x 1200 x 145 mm |
| Total weight per Palette | 0.00 KG |
| File Name | Description | File Size | Mime Type | |
|---|---|---|---|---|
| G200 & FS40 GL TAS00002DJ.pdf | New 2020 GL certificate | 285757 | application/pdf | Download |
| SGSwovenBelts.pdf | SGS Report | 187370 | application/pdf | |
| RoHsGW75PES.pdf | RoHS Report | 277567 | application/pdf | |
| REACH138_WOVEN STRAP.pdf | Reach Certificate | 293427 | application/pdf | |
| SVHC-5S Report Woven Strap.pdf | SVHC-5S Report | 1000154 | application/pdf | |
| 2017-SVHC-5 NEW-woven strap.pdf | 2017-SVHC-5 NEW-Report | 605518 | application/pdf | |
| Test_report_for_G200+GWS40RD.pdf | g200 Test report Jun 2017 | 289849 | application/pdf | |
| G200_&_FS40_GL_TAS00002DJ.pdf | New 2020 GL certificate | 285757 | application/pdf |
