| Product Code | G86 |
| Product Name | Woven Strapping - G86 - 25mm, 1200/1900 daN, 500m coil |
| Product Size | 25 mm (1") |
| Weight | 6.8240 KG |
| MOQ | 108 |
| Custom Tariff No. | 560750 |
| GTIN/EAN13 | 4251858211124 |
| Price |
Polyester Woven Strapping
Woven strapping belts are made of high tensile polyester yarns. Due to its material characteristics it has low elongation (below 10%), is highly tear proof and absorbs very little moisture. Furthermore the strapping can be retensioned in case of volume loss in the packaged goods and has a high breaking load, linear and within the system. Woven strapping belts will not splice, are flexible and universally applicable.
Specifications
| 1. Technical data | |
| Material | High tensile polyester yarns, woven |
| Material processing | Glue coated, pre tensioned and heat dried for higher strength |
| 2. Required standard | |
| Minimum linear breaking strength | 1200 daN |
| Minimum system breaking strength | 1900 daN |
| 3. Tested data | |
| Linear breaking strength | Test 1-5 ( 1232, 1222, 1201, 1230, 1203 ) Avg 1218 daN tested Aug 2017 |
| System breaking strength | see tested combination(s) below |
| System breaking strength+BF8S-2560P | Test 1-5 ( 1935, 1982, 1916, 1956, 1950 ) Avg 1948 daN tested Aug 2017 |
| System breaking strength+WB25N5.0 | Test 1-5 (1668, 1741, 1543, 1547, 1664 ) Avg 1633 daN Aug 2017 |
| 4. Shipping | |
| Custom Statistic code Tarif Number | 5806321000 |
| Place of Origin | China |
| Standard Container | |
| Items per Carton | 2 |
| Cartons per Palette | 54 |
| Net weight Carton | 20.18 KG |
| Gross weight Carton | 21.98 KG |
| Dimension Carton | 37 x 37 x 32 cm ( 0.043808m³ ) |
| Items on Palette | 108 |
| Palette size | 112*112*14.5 |
| Total weight per Palette | 790.99 KG |
| File Name | Description | File Size | Mime Type | |
|---|---|---|---|---|
| Woven Strap TUV report 2013.pdf | Woven Strap TUV report | 1423135 | application/pdf | |
| RoHSGW60PES.pdf | RoHs Report | 255694 | application/pdf | |
| SGSwovenBelts.pdf | SGS Report | 187370 | application/pdf | |
| REACH138_WOVEN STRAP.pdf | Reach Certificate | 293427 | application/pdf | |
| SVHC-5S Report Woven Strap.pdf | SVHC-5S Report | 1000154 | application/pdf | |
| 2017-SVHC-5 NEW-woven strap.pdf | 2017-SVHC-5 NEW-Report | 605518 | application/pdf | |
| Test_report_for_G86.pdf | G86 test report Aug 2017 | 229056 | application/pdf | |
| G86_&_BF8S-2560P_GL_TAS00002CV.pdf | New 2020 GL certificate | 285125 | application/pdf |
