Product Code G87
Product Name Woven Strapping - G87 - 25mm, 1350/2070 daN, 300m coil
Product Size 25 mm (1")
Weight 10.1500 KG
MOQ 108
Custom Tariff No. 5806321000
GTIN/EAN13 4251858211933
Price

Login to view Prices

ADDITIONAL PRODUCT IMAGES






Polyester Woven Strapping

Woven strapping belts are made of high tensile polyester yarns. Due to its material characteristics it has low elongation (below 10%), is highly tear proof and absorbs very little moisture. Furthermore the strapping can be retensioned in case of volume loss in the packaged goods and has a high breaking load, linear and within the system. Woven strapping belts will not splice, are flexible and universally applicable.

Specifications

  • no damage to most surfaces
  • no corrosion & easy handling
  • low investment cost
  • high shock absorption
  • a small, manageable system
  • limited resistance against lyes and acids
  • no risk of injury for shippers and consignees in using or opening the strapping
  • available width 13mm to 25mm
  • linear breaking strength available from 295 to 1500 daN
  • special glue coating for usage
  • for baling press machines available with special glue coating





1. Technical data
Material High tensile polyester yarns, woven
Material processing Glue coated, pre tensioned and heat dried for higher strength
2. Required standard
Minimum linear breaking strength 1350 daN
Minimum system breaking strength 2160 daN
3. Tested data
Linear breaking strength 1350 daN
System breaking strength see tested combination(s) below
4. Shipping
Custom Statistic code Tarif Number 5806321000
Place of Origin China
Standard Container
Items per Carton 2
Cartons per Palette 54
Net weight Carton 14.30 KG
Gross weight Carton 15.20 KG
Dimension Carton 35 x 35 x 32 cm ( 0.0392m³ )
Items on Palette 108
Palette size 112*112*14.5
Total weight per Palette 1212.40 KG
